linkedplaces.draw (part 1)

In Part 2, I describe the functionality in linkedplaces.draw to date. At some point, a collaboratively authored functional spec for a ‘proper’ crowd-sourcing tool will come together on GitHub.

I have been building a pilot tool for digitizing features from georeferenced historical maps (and maps of history such as found in historical atlases), tentatively named linkedplaces.draw. Its immediate intended use is for what we at the University of Pittsburgh World History Center have been calling “historical mapathons.” We are planning to facilitate, stage and encourage such events, in which individuals and small groups can virtually gather to harvest temporally scoped features from old maps, for their immediate use and for preparing contributions to World Historical Gazetteer (WHG) [1]. We have begun testing it by digitizing features for settlements, archaeological sites, regions, dynasties, and ethnic groups from the highly regarded “An Historical Atlas of Central Asia” (Bregel 2005).

linkedplaces.draw app (June 2020 alpha)

Fig. 1 – linkedplaces.draw app (June 2020 alpha)

Maps v. Texts as Gazetteer Sources

Old maps represent a largely untapped storehouse of information about geographies of the past. Digitizing features from maps that can be geo-referenced (a.k.a. geo-rectified, or warped) without too much distortion provides an estimated geometry that is invaluable. The most immediate use scenario driving development of WHG is mapping place references in historical texts and tabular datasets. But to make a digital map you need geometry, however approximate. Discovering suitable coordinates for lists of place names drawn from historical texts is far and away the most difficult and time-consuming task in this scenario. If your source texts are of a region and period it makes sense to build a gazetteer of that region and period using maps made at the time–and then to contribute the data to WHG so no one has to ever do it again! Certainly, the feasibility of deriving useful geometry in this way is reduced the further back in history one goes.

Maps made prior to the 18th century–beautiful, instructive, and useful as they may be–normally don’t have sufficient geodetic accuracy for this purpose (Fig. 2b). Obtaining geometry for place references made in earlier periods will require a different approach, e.g. capturing topological relations like containment. Also, one can also digitize features from maps of history, as we are doing with the Bregel atlas mentioned above.

a) S. America 1812, b) "Aphrica" (& Arabia) 1600

Fig. 2 – a) S. America 1812, b) “Aphrica” (& Arabia) 1600

The GB1900 Proof-of-Concept

Although hundreds of thousands of old maps have been scanned and made available for viewing and download by map libraries around the world [2], the names and estimated coordinates of features on them have not been transcribed in any quantity. The recent project GB1900 provided a successful proof-of-concept (cf. “The GB1900 project–from the horse’s mouth“). Crowd-sourcing map transcription software was custom built for the public at large to work with a single Ordnance Survey map, and over a period of months millions of names and geometries were digitized. Preliminary results can be viewed at; analytical products are sure to follow. Unfortunately the software used for GB1900 cannot be re-purposed for other maps and general use.

Unfortunately, although the code for the GB1900 crowd-sourcing software is available, it is not re-usable; at least I and others have been unable to revive it. Hence, linkedplaces.draw, which will hopefully serve as a demonstrator that could be used in finding funds to build a sturdy open-source platform that can be used by groups of any size–including “the crowd”–to do this valuable work.

Related Tasks and Software

Several existing free software packages and web sites provide users the capability to perform these tasks related to old map feature digitization, in some combination: a) georeference a map image and save the rectified result as a GeoTIFF, b) create web map tilesets from a GeoTIFF file, and c) display single images or tilesets as overlays on modern web base maps. Typically viewers for these provide an opacity control, allowing comparison of old and modern geography. This is all great, but what is missing is the capability to draw or trace features from the rectified images.

Coda (for the moment)

For years, computer scientists and others have explored the possibility of automated feature extraction. There are a few such efforts under way right now. I wish them godspeed, and do believe machine methods will ultimately be able to extract a list of names from some relatively recent map series having especially clear cartography, but also that they will never handle maps like Figure 2a, and will never successfully extract the estimated geometry of even point features. Yes I know, never say never. In the meantime…

[1] The World Historical Gazetteer project is building a web platform for developing, publishing, and aggregating data about places drawn from historical sources by members of the broad community of interest studying the past within and across numerous disciplines. A Version 1 launch is planned for June/July 2020. See the About pages and Tutorials as for details.

[2] The extraordinary David Rumsey Map Collection has many extended features and direct hi-res downloads; Old Maps Online is a “gateway to historical maps in libraries around the world.”

Posted in GeoJSON-T, historical mapathones, Linked Places | Leave a comment

linkedplaces.draw (part 2)

In Part 1 of this posting, I introduce the linkedplaces.draw (LPDraw) tool and briefly explain its motivation. This is a pilot software project, and has been put together fairly quickly to support historical mapathons we are undertaking at the University of Pittsburgh’s World History Center (WHC). These will produce historical place data that can be contributed to the World Historical Gazetteer platform. Figure 1 illustrates most functionality of the tool itself. Figure 2 below shows some screens in the “Dashboard” section of the app.

We are testing this alpha draft version now, and it will undoubtedly undergo changes and additions in weeks to come. In time, I plan to package the tool so that anyone hand with Django and PostgreSQL can stand up their own instance. But all this is simply a demonstrator for a “proper” crowd-sourcing app, which to realize will require a) design, b) funding and c) developer(s). Please get in touch with ideas about that.

Fig. 1 – linkedplaces.draw (LPDraw) main screen

One piece of a puzzle

The WHC workflow that the LPDraw tool will play a part in goes like this:

  1. Identify one or several maps, data from which will be useful for some research domain—typically of a particular region or region/period combination. These could be historical maps downloadable from an online resource like David Rumsey Map Collection, or via Old Maps Online. Or they could be paper maps, possibly from a print historical atlas.
  2. Georeference each map image, resulting in a GeoTIFF file for each.
  3. Create an xyz map tileset for each GeoTIFF. We are using MapTiler software for this. Note tileset details like the minimum and maximum zoom and bounds.
  4. Upload the tileset(s) to a web-accessible location
  5. Register as a user in the LPDraw app
  6. Create a project record and map records for each individual map in the project
  7. Identify, for the project as a whole or for each map, the feature types to be digitized, and a timespan representing temporal coverage of the project and/or each individual map.
    • Feature types will be presented as options in the interface, and timespans will be automatically added to each digitized feature (if that option is checked in the map record)
    • Feature types are not by default restricted to a particular geometry; points, lines, and polygons are all options
  8. Assign other registered users as collaborators able to create and edit features for the project.
  9. In the “draw” screen, choose a project and map from dropdown menus. The map loads and digitize features as desired.
    • Use the opacity control to view the underlying map, as an assist to proper placement
    • Enter a name or names in the popup, according to the LP-TSV format convention, e.g. separating variants by a ‘;’
  10. Download options available so far are Linked Places format (GeoJSON-compatible) and TSV.

Fig. 2 – linkedplaces.draw “Dashbord” screens (preliminary)

Posted in GeoJSON-T, historical mapathones, Linked Places | Leave a comment

Asked Twitter historians about ancient epidemiology and…

…got a ton of valuable information, references and links recently. A colleague I hadn’t seen in a while reached out to me on behalf of a student of his at Lafayette College, due to my involvement with the ORBIS project. The student is “interested in modelling the spread of disease in the ancient Roman world” and he “suggested that she investigate building cost surfaces with ORBIS and see if that could be used as an input in some sort of epidemiological model.” He asked me:

“…are you aware of any scholars…using ORBIS while investigating epidemiology in the ancient world?”

I tweeted an inquiry and within minutes, a stream of answers came back. I’ve pulled together most of them in quick and dirty fashion here, and made this post for quick reference by my friend and his student…and whomever. Also to note the generosity of people in this community I’ve had the enormous pleasure to be somewhat connected with.

From Monica Green ( @monicaMedHist

The field of historical epidemiology is in the middle of a paradigm shift. Retrieval of pathogen #aDNA (for the ancient world, that includes thus far #YersiniaPestis & #HBV & 2 malaria parasites) is the new gold standard for identifying historical disease confidently. Beyond that

… we can make plausible inferences from paleopathological indicators (e.g., bone lesions, intestinal parasite eggs) about the types of disease that were present. A major project is underway at Harvard to research the ancient Mediterranean:  At Princeton (

… a new database has been launched that focuses on plague in late antiquity:  I can’t say anything specific about the mapping components of either project yet. Deciding when & where specific diseases are found in specific populations is next challenge. (…)

You’ll need to communicate w/ the folks at Princeton about what their plans are. The Keller et al. study shared all their data on sites where they checked for #YersiniaPestis but couldn’t retrieve any. (Doesn’t mean there was no plague, only that DNA capture wasn’t successful.)

For an overview of what’s going on in #aDNA pathogen research, see this:…, and this:…. I’d also recommend your student dig deep into the Supplemental Data of Keller et al. 2019:…. It’s a trove of information.

I would add that if your student has not yet discovered the network analysis work of @Byzanzforscher (e.g.,…), it would be very good to look at. Again, applying this work to disease history is only as good as our disease data, which is mostly inferential.

From Johannes Preiser-Kapeller ( @Byzanzforscher

I dealt with some aspects of using the Orbis Network for epidemic Diffusion here: . Of interest is also the work of Marek Vlach, who presented a paper on modelling the Diffusion of the Antonine Plague in Brno last year: ( (…)

He gave a paper last year at the historical Network conference in Brno on the Antonine Plague, but as far as I see, it is still unpublished. But it was really impressive, maybe one can contact him directly, if interested.

reply from Monica Green

Thanks very much for this, Johannes. Obviously, there will be need to talk about these issues sooner rather than later, as dialogue grows btw palaeogenetics & the other historical fields. We’re trying to launch a #BlackDeath Digital Archive (#BDDA) which aims to move beyond

… the centuries of plague histories that keep parroting the same data & go back to original sources. The project just won the @CARMENmedieval Prize. In the meantime, on the issue of data quality there’s this must-read from our contributor @joris_roosen: (…)

BTW, Johannes, just to confirm: this () is the study by Vlach you were referring to, right? It only mentions the #AntoninePlague once, but yes, I can see where the possibilities of this might be leading. (…)

From Ryan Horne ( @RyanMHorne

Not so much in the ancient world, but we did have a @WHCPitt intern do some geospatial modeling of Ebola. A good primer for the networked aspect of epidemiology: (…)

Using some @BigAncientMed code w/@Gephi is a good place to start

I have used an effective combination of @Gephi / @cytoscape with network / r/outes data from #ORBIS / @AWMC_UNC, #pgRouting, and @BigAncientMed / custom code to combine force-directed graphs w/ spatial data to study this type of thing. I can send an article I am finishing up for #Classics@ about this very thing (great timing!) that is a fairly high-level overview about social-spatial networks, and can send more code / bibliography about the component parts if you want.


Posted in Uncategorized | Leave a comment

Notes for an Orbis-esque Hackathon

On July 18-20, I will join several other “interested digital humanists with an inclination for coding” gathering at the University of Vienna to consider what a generic version of ORBIS: The Stanford Geospatial Network Model of the Roman Empire (ORBIS:Rome here) could or should consist of, and to begin creating it. Several people have expressed interest in beginning a “Silk Roads Orbis” as a first example. I will participate in this effort and I’ve written up these notes to clarify my own thoughts. As the front-end developer for ORBIS:Rome v1 and a witness to v2 development, I may have some helpful insights 🤷🏻‍♂️.

The ORBIS:Rome development team discussed this concept several years ago, referring to it as “Orbis-in-a-Box.” In a 2015 article, ORBIS:Rome’s principal developer, Elijah Meeks, wrote, “the sophistication of ORBIS, which is among the most complex pieces of geospatial information visualization on the web, makes it difficult to replicate” [2]. But the idea that some useful principles and methods could be drawn from that work led Elijah to develop some generic JavaScript-based route-finding functionality, using a D3 mapping layout he had developed (d3-carto-map) and a JavaScript implementation of the Dijkstra algorithm. He published two examples, demonstrating one-to-one (“simple”) and one-to-many (“network flooding”) cases.

Simulated routes over a network vs. “modeling travels”

The idea of Orbis-in-a-Box has been one guiding thought for this meeting, but the announcement for it is titled “Modeling Travels in History.” ORBIS:Rome was all about route simulation, whereas “modeling travels” suggests particular journey events. The time costs associated with network segments should be derived in part from historical accounts of actual travel, but in my view these are two very different undertakings.

Apart from ORBIS-like route simulation, I am keenly interested in modeling events of geographic movement (see the Linked Traces pilot application). In the conceptual model and schema I developed for that with Rainer Simon and Lex Berman, historical movement data falls in three categories: journeys, named historical routes, and flows. Journeys and flows are eventive data; historical routes are courses of travel taken routinely over time by unspecified travelers (sets of segments).

Breaking Down ORBIS:Rome for OiB

The following outlines some system functions and related components.


The three principle functional categories in ORBIS:Rome are

Route finding: one-to-one least cost path
Given two places (a.k.a. sites, nodes), calculate the least-cost path for a simulated journey between them across a multi-modal network of roads, paths, rivers, and maritime routes. Journey cost is the sum of weights for its network segments (edges). Segment weights are derived from distance and some combination of “friction” estimates drawn from modern topography and historical sources. Results include duration, distance, and dependent on available data, a derived monetary cost of transporting commodities or people across it. Additional parameter choices for ORBIS:Rome include: season of travel, transport mode (vehicle, animal, foot), and network modes (road, river, open sea, coastal).

Cartograms, contour maps, and regions: one-to-many paths
The k-dijkstra algorithm allows very rapid calculation of costs between one node and many others. Results – ‘fields’ of point values in a large area – can be used to create several geospatial analytic products. Cartograms substitute time or other cost for distance, and distort maps accordingly. Contour maps show bands of roughly equal values for some value associated with point locations; in this context, time or expense for travel between a given point and all others in an area can produce isochrone and isodapane maps, respectively. Given several “start” points, one can also compute regions with clustering and Voronoi algorithms.

Application Programming Interface (API)
The internal API for ORBIS:Rome has not been documented for external access, but for OiB it could be. The number of allowed parameters may determine its usability. You can see what queries ORBIS:Rome generates dependent on UI choices, using the “Network” function in browser developer tools consoles. For example, calculating a route between Constantinople and Jerusalem with various parameter values looks like this: \
&tr=0&ts=0&p=0&ml=road,coastal,upstream,downstream,overseas, \
ferry,self,ferry,transferc,transferf,transfero,transferr \

It returns a complex JSON object that front-end code parses for display.


Network Data

  • Places (nodes). Point data for settlements and other related network nodes (e.g. coastal promontories).
  • Segments (edges). LineString geometry for paths; in ORBIS:Rome, principal segment (path) types include road, river, ferry, open sea, coastal. These are further subtyped to differentiate associated weights, which have been pre-calculated: e.g. river segments include upstream, downstream, fastup, and fastdown subtypes. There are also logical transfer segments to allow associating costs with switches between modes (e.g. road to ferry). The main edge table has 53,539 rows, for 7740 distinct node pairs. Arriving at plausible segment weights demands intensive historical research and/or geospatial analysis.
  • Segment weights. Segment costs can vary according to season and direction (upstream/uphill vs. downstream/downhill). We may wish to factor elevation change into weights. For ORBIS:Rome, historical sources indicating travel times between places were relatively sparse compared to what may be available for later periods.
  • Segment restrictions. In ORBIS:Rome, a number of segments are “restricted” – omitted from some calculations – in various circumstances, including “no go” in certain months, or not feasible for some transport modes.

Some data considerations

Temporality. Networks change over time, sometimes significantly. So do vehicle types and capabilities. Travel across the broadly defined terrestrial and maritime Silk Roads occurred over roughly 1500 years. The ORBIS:Rome network “broadly reflects conditions around 200 CE.” How should a generic OiB allow implementations to account for network change over time? With temporal attributes of nodes and edges? With discrete snapshot data subsets? Either?

Granularity. Data density for particular regions within a given OiB scope may be more or less sparse. This variation can affect results significantly. What should be best practice recommendations for this?

Resolution. Vector MultiLineString data can be created at various resolutions. The distance of a given path between two places will reflect how articulated the relevant segment linestrings are. Great variety in resolution can result in misleading results.

Paths versus simple edges. Edge data for ORBIS:Rome is “geographically embedded.” That is, it reflects approximate courses of roads, rivers, etc. It would also be possible to use simple edges that are “partially embedded,” with geometry fixed only at start and end, and to assign weights reflecting distance (among other things), but not representing actual paths. Should this be an option?

Software package design

How will users implement Orbis-in-a-Box for their particular study region and period? What “user stories” or “use scenarios” should drive development?

Ideally (?) a user could a) clone an OiB repository, b) install a relatively few dependencies on their system, c) make some edits to a configuration file for project-specific settings, including data source, d) run a local HTTP server on a specified port, and e) navigate to a GUI with a number of features that allow them to query and visualize their dataset. Once the application looks right and is giving proper results, it could be deployed to a public web server.

What are the features for a v1 of OiB? for a v2?

  • TBD



[1] Short for ORBIS: The Stanford Geospatial Network Model of the Roman Empire (
[2] Cf. “Creating an Application like ORBIS” in

Posted in routes | 2 Comments


In recent days, a conversation has been renewed about the prospects for an “Orbis-in-a-Box” platform (OIB) for simulating historical movement across multi-modal transport networks. The idea holds great interest for me, and this post is a hasty “my two cents.”


ORBIS: The Geospatial Network Model of the Roman Empire (ORBIS:Rome) was initially launched in May 2012 after something less than one year of intense development. A major upgrade to the site was completed in 2015 by its lead developer, Elijah Meeks. At initial launch, the number of visitors to the site wildly exceeded the project teams’ expectations, and six years later there are still on average 8-9,000 distinct user sessions per month. Although there are peaks and lulls in traffic, that number remains remarkably consistent. Walter Scheidel was the project’s principal investigator, and several of his students made substantial contributions. My own role was developing the front end for Version 1 and serving as something like a ‘geographer sounding board.’ Complete credits are found in the “About” section of the site.

In the Fall of 2012, Walter Scheidel hosted a mini-conference at Stanford to discuss the results of the project and speculate about next steps to be taken, if any. At that meeting, and in many settings since, all of the project team have heard inquiries along the lines of, “how can I make an Orbis of _____?” I think it’s fair to say Walter, Elijah and I all thought that was a commendable goal, but there wasn’t the time or funding context for it.

Not that I didn’t try: in 2015 I led the authoring of an NSF proposal titled “The Orbis Initiative,”” submitted by Stanford Libraries, that would have produced, effectively, a generic OIB platform. Although the proposal received high marks from reviewers, it fell short and we didn’t re-submit. In 2016-17, I turned my attention to another aspect of historical geographic movement: modeling journeys, named routes, and flows — specific and aggregated events _occurring on_ the roads, rivers, and sea lanes of multi-modal transport networks. Lex Berman, Rainer Simon and I developed a temporal extension to GeoJSON (GeoJSON-T, now GeoJSON-LDT) and I built a pilot web app, Linked Places to test it out against several kinds of data.

I still firmly believe an OIB platform would be used by many (?) historical scholars and be a valuable contribution. Apparently others feel the same way. As Maxim Romanov has recently suggested, maybe we can collectively take some steps in that direction, absent (for the moment) a big funding source.

The Use Scenario, aka User Story

We don’t have to make one up — the al-Ṯurayyā Project, led by Masoumeh Seydi (U Leipzig) and Maxim (U Vienna) could readily become a first user of OIB. But to state it in more generic terms:

A team of scholars, in the course of researching a particular region, period and themes, has developed a set of historical network data, and wishes to simulate movement along that network to better understand related events and historical processes of the study area. The data consists of named places (nodes) and route segments (edges, typically unnamed). Segments have been assigned costs associated with traversing them by various modes (e.g. vehicle types), possibly with seasonal variations. The costs are best estimates drawn from primary and secondary sources.

The team arranges their data in the format specified by the new OIB platform, downloads the OIB software from GitHub, and stands up an instance in their local development environment. They fill in several parameters in a configuration file specific to their project, including project title and data path, fire up a local web server, and navigate to a new graphical interface to their network. After making numerous adjustments to configuration parameters, and possibly some customizations to code, they deploy their OIB instance to a cloud server, route a domain name to it, and tweet out an invitation for people to use it.

Simple, no?

From Here to There

Some big obvious questions arise from this scenario, including: What functionality must the web interface have, and how generic can it usefully be? That is, what questions are being asked? What data will be required, and how readily can it be developed?

Regarding data, ORBIS:Rome required modeling maritime movement across the Mediterranean, part of the North Atlantic, and the Black Sea. This was enabled by Elijah’s inspired creation of a sea mesh. Assuming this method stands up as something to replicate, other parts of the world would need other meshes. Travel across larger bodies of water were really constrained by seasonal trade winds, as I’m learning reading “Pathfinders: A Global History of Exploration” so global meshes may be unnecessary.

Regarding functionality: in ORBIS:Rome, seasonal segment costs in terms of effort and dinarii are “baked in” — should OIB permit adjustment of these values by users (not only authors/publishers)?

How to Begin?

A few possibilities:

  • Launch an OIB Working Group of Pelagios Commons? The deadline for this years’ mini-grants is Wednesday(!)
  • Collectively decide upon a useful first phase of effort that can be realistically accomplished given time and money constraints.
  • Get that started at a hackathon, pre-work for which might include: surveys of existing ORBISs:Rome code (or not!)
    • The algorithms and data models of Orbis:Rome are not well documented (costs extra, no time!); a pseudo-code representation of them might be a useful starting step. Its PHP code could be ported to a more modern language/platform, and undoubtedly refactored. Fresh eyes by other developers would certainly lead to improvements.
    • A survey of the existing functions, followed by a group assessment of how generic they are, as well as priority v. effort ranking. The same for graphical elements and widgets.









Posted in routes, Uncategorized | Leave a comment

User Stories for the World-Historical Gazetteer

My work designing and developing the World-Historical Gazetteer (WHGaz [1]) is under way. This NEH‑funded 3‑year project is based at the University of Pittsburgh World History Center and directed by Professor Ruth Mostern. David Ruvolo is Project Manager, and Ryan Horne will contribute in his new post-doc role at the Center. I’m very pleased to serve as Technical Director, working from Denver.

The project actually comprises more than a gazetteer.  An official description of the project’s goals and components is forthcoming; in the meantime, its deliverables include:

A gazetteer, defined in the proposal as “a broad-but-shallow work of common reference consisting of some tens of thousands of place names referring to places that have existed throughout the world during the last five hundred years.”

Interfaces to the gazetteer, including

  • a public API;
  • a public web site providing graphical means for data discovery, download, and visualization, and serving as a communication venue for the community of interest;
  • a web-based administrative interface for adding and editing data

An “ecosystem”, described as “a growing and open ended collection of affiliated spatially aware world historical projects,” seeded by two pilot studies concerning the Atlantic World and the Asian Maritime World

Models, formats, vocabularies. The conceptual and logical data models, data formats (e.g. GeoJSON-T), and controlled vocabularies (e.g. place types) developed for the project will be aligned with solid existing resources and published alongside data

Documentation. Software developed for the project will be maintained in a public GitHub repository. Additional documentation will be produced in the form of research reports published on the website and scholarly articles appearing in relevant journals.

What, for whom, and why

One of our first steps is developing “user stories” for the project, an element of the Agile development method that is a simple and effective way of capturing high-level requirements from users’ perspectives. I polled developers of some of our cognate projects (Pelagios, PeriodO, Pleiades) and added ideas stemming from their experiences to my own in creating the following preliminary list. If you can think of others that aren’t accounted for, please add them in a comment or email me. In my own streamlined version of Agile (Agile-lite?), user stories lead more or less directly to schematic representations of features supporting functions, then to coding. Evidence of streamlining is found in the detail already in place under items 18 and 19 (thanks, Ryan Shaw).

The next appearance of the features suggested by these stories will be in ordered lists of GitHub “issues” – coming soon.

user: anyone of the following
researcher: academic or journalistic
editor: of WHGaz data
developer: anyone building software interfaces to WHGaz services
hobbyist: amateur historians, genealogists, general public
teacher: at any level

User stories

  1. As a {user}, I want to {view results of searches for place names in a map+time-visualization application} in order to {discover WHGaz contents}
  2. As a {user}, I want to {discover resources related to a search result} in order to {learn more about the place and available scholarship about it}
  3. As a {user}, I want to {learn about the WHGaz project: its motivations, participants, methods, work products, timeline} in order to {determine its quality and relevance to my purposes; see where my tax dollars are going}
  4. As a {user}, I want to {suggest additions to the WHGaz} in order to {make the resource more complete/useful}
  5. As a {researcher} I want to {publish my specialist gazetteer data for ingest by centralized index(es)} in order to {make my data discoverable by place and optionally, by period}
  6. As a {researcher} I want to {search a geographic area (i.e. space rather than place)} in order to {find sources relating to places in this area}
  7. As a {researcher} I want to {find historical source documents, incl. by keyword search} in order to {identify which places they refer to}
  8. As a {researcher} I want to {compare historical sources} in order to {see how they might be related to another through common references to place}
  9. As a {researcher} I want to {compare the geographical relationships (and names) represented in ancient texts with historical and modern representations}
  10. As a {researcher/developer} I want {different options for re-using data (from data downloads, to APIs and embeddable widgets} in order to {enrich my own work/online publication}
  11. As a {researcher/developer} I want to {locate individual or multiple authority record identifiers for toponyms tagged in source material} in order to {find related research data}
  12. As a {researcher/developer}, I want to {retrieve WHGaz data in any quantity (filtered set, complete dump) according to multiple search parameters, using web form(s) or a RESTful query} in order to {re-use the data for any purposes, according to WHGaz license terms}
  13. As a {researcher/developer}, I want to {learn how to construct API queries} in order to {incorporate WHGaz data in my analyses/software}
  14. As a {researcher/hobbyist} I want to {embed a WHGaz map in a wordpress blog}
  15. As a {researcher/hobbyist} I want to {display places and movements (!) presented in specific texts} in order to {understand the spatial-temporal context of a text}
  16. As a {teacher} I want {quick lookup tools linked to authoritative information} in order to {use the data in teaching}
  17. As an {editor}, I want to {add and edit place records} in order to {make the WHGaz resource more complete/accurate/useful}
  18. As a {developer} I want to {query WHGaz programmatically, returning GeoJSON/GeoJSON-T features in JSON lines format, each having 1) a “properties” object including (a) an identifier, (b) one preferred label and one or more alternate labels (w/optional language tags), (c) name and URLs of the gazetteers to which it belongs; 2) a geometry object; and 3) a “when” object describing temporal extent} in order to {use external gazetteer data in the my (PeriodO) client interface}
    • Allow querying by:
      • providing text to be matched against feature labels
      • specifying a rectangular bounding box (option to include all intersecting features or only those contained within it
  1. As a {developer} I want to {query WHGaz as above via a GUI, with option to filter results by gazetteer} in order to {browse and/or download records}
    • Entering text into the text input should display a list of matching feature labels, in sections titled by gazetteer name
    • Hovering results list should display/highlight feature on map; zoom to feature (?)
    • Selecting a particular result from the list should raise popup with info about it
    • The map display needs to support custom tile sets including the Ancient World Mapping Center’s.

[1] WHGaz is an unofficial short form used in this post; official naming will undoubtedly ensue

Posted in Uncategorized | Leave a comment

Linked Places v0.2

Fig. 1 - Linked Places sandbox

Fig. 1 – Linked Places sandbox

I’ve just re-launched Linked Places (, a sandbox web application for experiments in representing historical geographic movement: journeys, named routes (and route systems), and flows. Linked Places displays several exemplar datasets formatted as GeoJSON-T, my proposed temporal extension to the venerable GeoJSON.

The site features and functions bear some explanation, as they’re not all immediately apparent.

Historical geographic movement data:
Journeys, Routes, and Flows

Last fall, Lex Berman, Rainer Simon and I came up with draft conceptual and logical models of historical geographic movement, which are described in some depth in blog posts here and here. Briefly, we posit three classes of movement we wish to model.


Fig. 2 - Seven journey, flow, and route datasets

Fig. 2 – Seven journey, flow, and route datasets

Journeys are events—individual occurrences of one or more persons moving between two or more places over some period of time. Journeys are often typed according to purpose (pilgrimage, expedition, migration, march, Grand Tour, etc.) or mode of travel (voyage, flight). Spatial data for journeys always includes two or more places (i.e. an itinerary), normally ordered temporally. The actual paths traveled between places may be known, unknown, estimated, or ignored. Similar variation in completeness holds for temporal attributes as well: we might know the year(s) or decade(s) the journey took place, dates for some or all departures and arrivals, durations of segments, or simply sequence. Linked Places depicts two pilgrimages from the 4th and 7th centuries, and a recent 5-month journey of my own I called “Roundabout.”

Named routes and route systems (hRoutes)

Routes are the named courses of multiple journeys known to have occurred over a period of time (notably, for trade and religious pilgrimage); they are differentiated from the physical media for those journeys (roads, rivers, etc.). That is, a route may comprise segments of multiple roads and rivers. Exemplar route data in Linked Places are for Old World Trade Routes, Ming Dynasty Courier Routes, and the pilgrimage route described on the Vicarello Beakers.  Other well-known route systems include the Silk Road, the Pilgrimage Routes to Santiago de Compostela, the Incense Route, the Amber Routes.


Flows are aggregated data about journey events; that is, the movement of something at some magnitude over some period of time. The Incanto Trade flow example in Linked Places aggregates data about the number of ships involved in 840 individual commercial voyages outward from Venice between the 13th and 15th centuries.

A map and data-dependent temporal visualization


Fig. 3 – Four types of temporal visualizations

Linked Places consumes data in GeoJSON-T format and renders it on the fly to a web map and one of four kinds of temporal visualization depending on the nature of the data:

  1. a timeline of events (journeys)
  2. a timeline depicting a relevant period and its immediate context, drawn from PeriodO collections (where period is the only temporal information known)
  3. a histogram indicating the number of segments valid for a period (time-indexed trade routes)
  4. a histogram indicating magnitude of flows per period

The color for journey segments is scaled: earlier=lighter, later=darker

Linked Data

Fig. 4 - Place popup links to external gazetteer, segment search for connections

Fig. 4 – Place popup links to external gazetteer, segment search for connections

Place dialog popups include links to gazetteer APIs, including Pleiades, GeoNames, and the temporal gazetteer (TGAZ) of Harvard’s China Historical GIS.

Period timelines for Courier, Vicarello, and Bordeaux datasets are drawn dynamically from the PeriodO API, rendering the relevant period and adjacent neighbors from a collection.


Query a union index of selected fields in all Place records from the 7 individual project gazetteers. Results are grouped by dataset, and leverage name variant data within Place records. For example, Dubrovnik and Ragusa are known to refer to the same place.

The “Find connections” link in place popups (Fig. 4) queries identifies segments associated with a given place from all 7 datasets.


The GeoJSON-T format is a work-in-progress. Code and preliminary documentation is available at its GitHub repository.

Briefly, GeoJSON-T:

  • Permits adding an optional “when” object to Features in one of two locations
    • as a sibling to “geometry” in a Feature
    • as a sibling to “coordinates” in each member of a GeometryCollection
  • Leverages GeometryCollections for changing geometries over time (similarly to the HistoGraph project) and permits “properties” in GeometryCollection members
  • Will be processed by existing GeoJSON-compatible software, simply ignoring “when” objects and processing geometry and properties found in the standard places
Posted in GeoJSON-T, routes | Leave a comment

A Case for GeoJSON-T

GeoJSON has become a popular standard format for representing geographic features in web mapping applications. It is supported by the key JavaScript libraries Leaflet, Mapbox, OpenLayers, and D3, and to some extent by desktop GIS software (QGIS, ArcMap). GitHub renders valid GeoJSON as simple maps, and web-based utility applications like and GeoJSONLint help users create, edit and validate it.

As the name suggests, GeoJSON-T adds time to GeoJSON. Geographic features, defined broadly[1], include events we want to map and analyze (e.g. births, deaths, battles, journeys, publication). For many analyses and mapping tasks, the temporal attributes of geographic features are as important as their geometry. Furthermore, many non-eventive geographic features–settlements, polities, buildings, monuments, earthworks, archaeological finds and so on–have essential temporal attributes.


Figure 1 – Xuanzang’s 7c pilgrimage in Linked Places demo

It is hardly controversial that a great many natural and fictional phenomena have a relevant spatial and temporal coverage (cf. Dublin Core), or setting.[2] Shouldn’t the de facto standard for geographic feature data account for time?

It could be (and has been) argued that time can be added to a GeoJSON feature as a member of its “Properties” element, organized however one sees fit. Certainly true, and many have. At issue is whether there should be a simple accepted standard location and format for temporal information within a GeoJSON Feature. If there were, a) new software, or new versions of existing software, could parse those temporal elements and render them to timeline visualizations[3], and b) data from multiple projects could be linked and analyzed by means of period assertions or computed “temporal topology” (e.g. Allen’s interval algebra[4]: equals, overlaps, before, after, starts, finishes, meets).

How would this work?

The first conceptual step is a simple matter: wherever a “geometry” element is required in GeoJSON, an optional adjacent (sibling) “when” element is allowed. Existing software supporting GeoJSON would simply ignore these and function normally. New software, or new versions of existing software, would parse them and offer visualization and analytic functionality. In the Linked Pasts demo prototype, I render “when” elements to a timeline using the venerable if outdated Simile Timeline library, linked to the “geometry” elements rendered traditionally to a Leaflet map (Figure 1).

Developing a standard

It’s well and good to say, “wherever there’s a ‘geometry’ allow an optional ‘when’,” but the devil is in the details. What is required and allowed in that “when?” I’m not experienced at ringleading standards development; what I’ve done for starters is create a provisional standard for discussion, then made the aforementioned demo app as proof-of-concept. The “when” looks like this:

"when": {
  "timespans": [["-323-01-01 ","","","-101-12-31",
     "Hellenistic period"]],
  "duration": "?",
  "periods": [{
    "name": "Hellenistic Period",
    "period_uri": ""
  "follows": "<feature or geometry id>",

An explanation of each element:


Optional. A sibling of “geometry” in a Feature (a), or of “coordinates” in a member of a GeometryCollection (b)


"type": "FeatureCollection",
"features": [
 "type": "Feature",
 "id": "",
 "properties": {},
 "geometry": {},
 "when": {}


"geometry": {
 "type": "GeometryCollection",
 "geometries": [
    "type": "LineString",
    "coordinates": [[93.867,40.35],[108.9423,34.26]],
    "when": {}


Required. An array of one or more 5-part arrays, the positions of which are Start, Latest Start, Earliest End, End, Label. Of these, only Start is required. The first 4 positions accept any ISO-8601 temporal expression, with the ‘accepted convention’ of a minus sign for BCE years. Label is an optional short text string that would (presumably) appear alongside a visual representation of the timespan.


Required. A null value indicates the phenomena occurred (or was valid) throughout the feature’s Timespans. If it occurred only for some part of it/them, enter an integer followed by a single letter code for the increment (d=days; m=months; y=years) or a “?” for an unknown duration. For example, a weeklong festival at some unknown time within a year timespan would be indicated as “duration”:”7d”; a birth as (perhaps) “duration”:”1d”

I anticipate timeline visualizations will be find this distinction essential; a birth for example does not occur throughout a year.


Optional. An array of Period objects defined in an external period gazetteer (e.g. PeriodO, each with a “name” and “period_uri” that can be dereferenced dynamically.


Optional. If the Feature or GeometryCollection member is in a meaningful sequence, enter the internal identifier of the element it follows here. Software indicating order or directionality visually or in lists will make use of these values if present.

Next Steps

I’d like to move the development of GeoJSON-T into a more formal process, but perhaps that should follow more informal discussion. A more detailed explanation of GeoJSON-T and its implementation for data about historical movement — journeys, flows and named routes — appears in the Topotime GitHub repo.

Please let me know your views on how we might proceed, by twitter (@kgeographer) or as a GitHub issue or preferably both. In the meantime, I will continue converting exemplar datasets into the provisional format outlined here, and developing software and utility scripts to manage, display, and even analyze it.

[1] A GIScience-ish definition for geographic features: “Phenomena on or near the earth surface for which location and other spatial attributes are integral for understanding and analysis.”

[2] An ontology design pattern for Setting was proposed in Grossner, K., Janowicz, K. and Keßler, C. (2016). The Place of Linked Data for Historical Gazetteers. In R. Mostern, H. Southall, and M.L. Berman (Eds.). Placing Names: Enriching and Integrating Gazetteers. Bloomington: Indiana University Press.

[3] As I have begun demonstrating with Linked Places work (


Posted in GeoJSON-T, routes, Uncategorized | Leave a comment

Linking Linked Places

A little context

The tag line for the Pelagios Commons web site is, “Linking the Places of our Past,” and that project is indeed facilitating the linking of historical place attestations published in digital gazetteers. From my perspective (and many others’) , the initiative is going great, bravo!

There are other ways that places are or have been linked and I’ve been plugging away at a facilitating representations and analysis of those connections in a couple of ways. The first was The Orbis Initiative, an ambitious and sadly unsuccessful NSF grant proposal to develop software and systems for extracting information about roads, rivers, canals, railways, and footpaths–and the places connected by them–from the million or so high-quality scans of historical maps. That data is of the physical channels (a.k.a. media, ways) used for the movement of people and goods across the earth surface. Although the grant wasn’t awarded, I’m happy to say a manageably-sized portion of the work it described was taken up by the CIDR team at Stanford University Libraries, just as I was leaving (amicably) in September. I expect fantastic results!

Since that work on geographic networks is in such good hands, I’ve begun to focus on the other side of that coin, the movement over such networks: individual journeys, named historical routes and route systems, and flows. I’m calling the project Linked Places (GitHub repository), and a mini-grant from Pelagios Commons has helped to jump-start it. It’s part of my larger DH/GIScience research frame, Topotime, which has a broad goal of joining Place and Period in data stores and software for historical research and education.

Enough context, this blog post is intended to describe the status of the Linked Places work products.

Linked Places Phase Two Status

I’ve described the goals of Linked Places and its early results in two blog posts on Pelagios Commons earlier this year (July and October respectively). In Phase One, Lex Berman and Rainer Simon joined me in clarifying a conceptual model for what we wanted to do, refining a provisional spec for a GeoJSON temporal extension (GeoJSON-T), then adapting the GeoJSON-T format for representing route data. We agreed on the term route for an overarching class encompassing journeys, flows, and historical routes and route systems (hRoutes). The conceptual model was then “expressed” in the GeoJSON-T form (Figures 1 and 2).

In Phase Two, I holed up in beautiful Ascoli Piceno to a) convert five exemplar data sets to a generic CSV form, b) write Python scripts to transform that CSV to GeoJSON-T and to populate an ElasticSearch index, and c) build a demo web map application that consumes GeoJSON-T data and puts it through some paces. That app, which mashes up Leaflet/Mapbox map with a Simile Timeline, is not designed as such–it’s been thrown together for discussion about what real apps might be interesting. I will be presenting this now completed Phase 2 work at the Linked Pasts workshop in Madrid, 15-16 December 2016.

Linked Places Work Products


GeoJSON-T simply adds an optional “when” element to native GeoJSON. That “when” is typically placed at the same level as a “geometry” element (the “where”), which can appear in a couple of places: as a top-level attribute of a Feature (Figure 1), or, in the case of routes data, as a member of a GeometryCollection (Figure 2). The GeoJSON GeometryCollection is a relatively infrequently used construct, but is essential to how we represent journeys and hRoutes. There is some more explanation on the Github wiki.

Figure 1. Generic GeoJSON-T Feature, with “when” member in a FeatureCollection (simplified gazetteer record)


Figure 2. Route feature (featureType Journey); segments are geometries in GeometryCollection



I’ve made the assumption that a large proportion of historical route data will be developed in spreadsheet or CSV format natively. Attributes and coding terminology will of course be distinct for every project that develops data. There’s nothing to stop anyone from creating GeoJSON-T route data from scratch, by whatever means, but if a researcher can rearrange their CSV data in a standard form, it can be converted and ingested automatically for use in the existing demo or future GeoJSON-T compatible applications.

At present, one would need to create two CSV files, one for places, and one for route segments. The core fields that are required, but in cases can have null values, are:


[‘collection’, ‘place_id’, ‘toponym’, ‘gazetteer_uri’, ‘gazetteer_label’, ‘lng’, ‘lat’]


[‘collection’, ‘route_id’, ‘segment_id’, ‘source’, ‘target’, ‘label’, ‘geometry’, ‘timespan’, ‘duration’, ‘follows’]

Following these, data files can have any number of further attributes/columns, which will appear in various ways within any given app. A complete accounting of these fields, and further details about data preparation and the Python conversion/ingestion scripts ( and will appear on the GitHub repository wiki soon. If you are anxious to play with this stuff before then (or afterwards), get in touch with me directly.

Linked Places Demo App

The GeoJSON-T format and its implementation for route data allows for some interesting display and analysis possibilities. The app so far only explores the visualization side. I’m planning to follow up this work with at least two “real” applications that do more: one for data exploration and discovery across a large distributed corpus/repository, and a second that allows manipulation and analysis of a given network of geographic movement (e.g. commodity flows like Incanto Trade, or route systems like the Ming Courier Routes). I’ve identified a few other exemplar datasets and welcome inquiries for collaboration.


Load one or more datasets; view linked gazetteer records for places; events or optionally “fuzzy” periods rendered on timeline

Linked Places screenshot 01

Search for Places, identify all members of its “conflation_of” set; and all route segments associated with it, from multiple datasets

Linked Places screenshot 02

Rudimentary timeline visualization (Simile Timeline); timeline and map features are linked

Linked Places screenshot 03

Load places and segments for flows and hRoute systems (nodes and links/edges) into D3 force-directed graph; download GeoJSON-T

screen capture, D3 graph visualization

View linked Place gazetteer data (Pleiades, TGAZ, Geonames)


View linked Period gazetteer data (from



The results of this work: a conceptual model for routes (journeys, flows and historical routes/route systems), the GeoJSON-T extension, its implementation for route data and reliance on CSV input, and last but not least the map/timeline mashup, are all provisional and experimental. The models have been tweaked (‘refined’) as requirements come to light, and that should continue for at least a little while longer. I welcome comments — here, on twitter (@kgeographer), via the project GitHub repo, or by email: karl[dot]geog[at]gmail[dot]com.




Posted in GeoJSON-T, routes, Uncategorized | Leave a comment

Event Centrality

I have been making a case for events in geo-historical information systems, periodically so to speak, over the past several years. Since I went “alternative-academic” (alt-ac) after completing my Geography PhD in 2010, I have neglected to publish material out of my dissertation—something I was cautioned strenuously against. I will begin rectifying that in bite-sized chunks on this blog; in time, maybe even write an article for an open access journal.

After nearly five years of building interactive scholarly works [1] others had in mind as a digital humanities research developer at Stanford, I’m moving on this Fall, and revisiting some of the things I was going on about in that dissertation. Oddly enough, I took a geography degree in order to better understand human history. Also odd perhaps is that I still like a lot of what I wrote.

It is titled “Representing Historical Knowledge in Geographic Information Systems,” and worth noting I was referring to (lower case, generic) geographic information systems, not GIS software packages like QGIS or ArcMap. Had no idea they were conflated so completely outside the discipline. Anyway, I began the introduction this way:

“The conceptual vehicle by means of which historians construct or analyze the contingency and temporal fatefulness of social life is the event. Historians see the flow of social life as being punctuated by significant happenings, by complexes of social action that somehow change the course of history.”

                                                                                                           (Sewell 2005:8)

Complex historical events are dynamic geographic phenomena: they comprise human activity associated with particular locations on the earth surface, and their participants’ locations and attributes over time are integral to their analysis.

Events are the central and most comprehensive container for information about dynamic geo-historical phenomena. To describe an event well is to account for its purpose and results, its participants’ roles in component activities during some interval, its setting in terms of space-time locations and relevant condition states, and its relation to other events, including as elements of historical processes.

The representation of large numbers of events along those dimensions will enable a powerful “faceted browsing” capability, and spatiotemporal analyses supporting the discovery of underlying processes. The power of events as information containers will stem in large part from typing them along their numerous dimensions.

After four chapters explaining my ontology engineering methodology and analyzing print historical atlases to discover some of what I called “the stuff of history,” in Chapter 5 I finally got around to elaborating the case and citing the articulate originators of CIDOC-CRM:

If we make a simple graph of the things in atlas maps—say events, people, material objects, and settings—we see the only object directly connected to all the others is the event. Virtually all relationships between persons, things and places are a function of, or mediated by, events (Figure 5-1).

Doerr and Iorizzo (2008) describe how its (CIDOC-CRM) event-centered approach permits “a picture of history as a network of lifelines of persistent items meeting in events in space/time […],” an “extraordinarily powerful” model supporting a “surprising wealth of inferences” (p. 5-8).


Figure 5.1 Event centrality


From that simple conceit, I went on to postulate that:

… just as physical objects are composed of one or more material substance, discrete temporal objects like events are composed of activity. At least it will be useful in the design of certain information systems to represent things as such, whether or not in actuality there is something in the temporal realm corresponding to matter in the physical realm.

Then I drew a slightly crazy figure to illustrate that notion (a = activity, e = events, pr = processes, pd = historical periods, s = states):


Following that (skipping a step or two), I framed the engineering tasks to follow by enumerating six primitive “constructs” (I prefer “patterns” now) that are key elements of historical knowledge representation: Events and Participation; Place; Groups and Membership; Historical Periods; Historical Processes; and Attribution.

Not coincidentally, I’m finding that the research I’ve pursued since has focused on a few of these, which are interwoven when one approaches particular systems, such as historical gazetteer services and applications blending maps and timelines.

In particular a new (to me) pattern, of Setting merges Place and Historical Period has emerged in response to requirements of particular systems and applications. My work on Topotime is a result. I do think this is the way ontology design patterns are supposed to work: as modular and often connecting pieces expressing conceptual and theoretical bases for data models and interchange formats.

[1] Interactive Scholarly Works is a term I came up with back in the day, when Elijah Meeks and I worked out a taxonomy comprising Interactive Scholarly [Objects, Works, Publications] reflecting the range of things we were building at Stanford.


Doerr, M. & Iorizzo, D. (2008). The dream of a global knowledge network—A new approach. ACM Journal on Computing and Cultural Heritage 1(1): 5.1-5.23.

Sewell, W. H. (2005). Logics of history. Chicago: University of Chicago Press.


Posted in Uncategorized | 2 Comments
